19" SOHOline cabinets provides an economical solution for wall mount mini cabinets. The SOHOline features a modular, sturdy and compact design, ideal installations for,
 Offices
Computer Aided Classes
Schools
Government Offices
Hotels
Branch Offices
REDUCE: %70 SHIPMENT , %50 LABOUR COSTS
Packing: Unit comes in a FLAT PACKAGE, minimum assembly reaquired. Load Carriying capacity: 30kg.
STANDARDS : IS09001:2000 , 19" mounting to IEC 297-1 , Overall cabinet dimensions to IEC 297-2
COMPLIANCES: UL and cUL
FEATURES
Easy to access
Front door features a full-length smoked and shatterproof glass door integral locking mechanism.
Rear door; removable with 4 screws.
Cable access
Pre-punched two(2) brush openning, one on top, one on bottom. Removable rear cable access panel.
Construction
Rigid frame construction in steel sheet, rapidly dismantled per 3 screw per corner. Top base is vented, pre-punched holes ara available for top mount cooling system. 19" mounting angles (front/2ea.) and allow for flexible configuration and adjustable in depth.
Extensive range of accessories
width=520mm. depth=400mm |
| ORDER NO. |
U
(44.45mm) |
H
inside height (mm) |
H
outside height (mm) |
flat package dimension (wxdxh) |
SOHO7U40 |
7 |
314,3 |
359,1 |
555×422×125 |
SOHO9U40 |
9 |
403,2 |
448 |
620×540×130 |
| SOHO12U40 |
12 |
536,55 |
581,35 |
620×540×130 |
| SOHO6U30** |
6 |
269,85 |
314,65 |
555×422×125 |
(**for 6U depth 300mm)
NOTE: Standard colour is RAL7035 white. For different colour options, please call to sales department. Unless noted otherwise, it is shipped RAL7035 vhite colour.
|
